1000LPH UF System Industrial-Grade Water Purification Plant
UFS-4 Series Water Purification System Commercial-Grade High-Stability Equipment
AQUALITEK 1000LPH UF System Industrial-Grade Water Purification Plant - 1000LPH High-Flow Ultrafiltration System delivering reliable, energy-efficient ultrafiltration. Industrial-Grade 1000LPH Ultrafiltration Purification System for industry, municipal and food processing.
This system typically features fully automatic operation and scheduled backwashing. It is primarily used as a pretreatment unit in reverse osmosis systems or to provide high-quality drinking water for commercial venues such as hotels and schools. It is an efficient and reliable physical filtration solution.
Working Flow
Production Water: After pretreatment, raw water is pressurized by the feed pump and enters the ultrafiltration membrane module. Under pressure, water molecules permeate the membrane wall as "product water" (purified water), and contaminants are trapped.
Backwash: After a period of operation, the system automatically enters backwash mode. The backwash pump drives product water from the product side into the membrane module in reverse, flushing the membrane fibers. Concentrate and contaminants are discharged from the inlet side.
Forward Flush: After the backwash is complete, a brief forward flush is performed to completely remove loose contaminants from the system.
Chemical Cleaning: When the transmembrane pressure (TMP) rises to a set value or the product water rate drops to a certain level, the system will prompt or automatically initiate a chemical cleaning.
Model List
|
Model No. |
Model Capacity(tph/gpd) |
No.of UF membranes |
|
UFS-2 |
0.7/4400 |
2 |
|
UFS-4 |
1.4/8800 |
4 |
Machine Detail
Featrues
✔️Better water quality, healthier water: It thoroughly removes harmful microorganisms such as bacteria and viruses while retaining beneficial minerals, resulting in safe and delicious water.
✔️High precision and efficiency: Filters down to 0.01 micron precision, using physical screening for high efficiency and stable, reliable results.
✔️Low energy consumption and cost savings: Driven by a low voltage, it requires no heating or high pressure, resulting in low energy consumption, a high degree of automation, and reduced labor costs.
✔️Eco-friendly and compact: No large amounts of chemicals are required, resulting in minimal wastewater. The equipment occupies a small footprint, and its modular design facilitates installation and expansion.
✔️Gentle Process, Preserving Activity: As a purely physical filtration process, it operates at room temperature, without introducing chemical reactions or generating heat.
✔️Powerful Pretreatment Protection: Ultrafiltration as a pretreatment before a reverse osmosis (RO) or nanofiltration (NF) system can significantly reduce the contamination burden of subsequent precision membrane systems, significantly extend the cleaning cycle and lifespan of RO/NF membranes, and thus reduce the long-term operating and maintenance costs of the entire system.
✔️Simplified Process, Improved Efficiency: Ultrafiltration can replace traditional multi-stage treatment processes (such as sedimentation, sand filtration, activated carbon filtration, and other steps) by simplifying multiple steps into a single process.
✔️Relatively Strong Water Quality Adaptability: For raw water with high turbidity and fluctuating water quality, the ultrafiltration membrane, through the filter cake layer formed on its surface, can achieve "dynamic optimization." This means that within a certain range, even when the inlet water quality deteriorates, the produced water quality remains relatively stable, demonstrating excellent resistance to shock loads.
Applications
💧Safe Drinking Water Production: Used in municipal tap water, residential drinking water, and bottled water, it thoroughly removes bacteria and viruses to ensure drinking water safety.
💧Desalination Pretreatment: Serves as the core pretreatment unit in reverse osmosis (RO) systems, protecting RO membranes from contamination and extending their lifespan.
💧Industrial Water Treatment: Treats various industrial wastewaters, removing impurities to meet recycling or discharge standards, saving energy and reducing consumption, and enabling industrial wastewater reuse.
💧Food and Pharmaceutical Industries: Used for clarification and sterilization of juice, alcohol, and milk, as well as ambient temperature concentration and purification of enzyme preparations and pharmaceuticals to preserve product activity.
💧Other Specialty Separations: Used in the production of sterile medical water and purification of marine aquaculture water.
AQUALITEK 12TPH Industrial UF Water Treatment Device (UFL-4 Series) delivers high-efficiency, high-throughput ultrafiltration with Automatic Backwash Technology, high fouling-resistance membrane modules for efficient pretreatment and turbidity reduction in industrial and commercial applications.
AQUALITEK 4TPH Industrial Reverse Osmosis Water Purification RO System, high-efficiency industrial-grade RO water treatment plant for manufacturing & processing, commercial reverse osmosis filtration system ideal for electronic component cleaning water use.
Our 500 LPH Reverse Osmosis (RO) System is engineered to provide high-quality purified water for commercial applications. Designed with advanced RO technology, durable components, and a user-friendly interface, this system ensures consistent performance, low maintenance, and long-term reliability.
With its compact design and robust skid-mounted frame, it’s an excellent choice for businesses that demand efficiency and quality in water purification.
Our 250 Liters Per Hour (LPH) Seawater Desalination Machine is designed to provide clean, safe, and fresh drinking water directly from seawater. Using advanced Reverse Osmosis (RO) membrane technology, this compact desalination unit is ideal for resorts, fishing vessels, offshore platforms, and island communities where freshwater is limited.
